FoundationDB's versionstamps should be everywhere

In this post I'll argue that versionstamps are a great primitive, and database systems other than FoundationDB should support them.

Versionstamps enable advanced use cases in distributed systems (including anything with a frontend that needs data from a server), such as optimistic concurrency control and change data capture (CDC).

What is a versionstamp?

A versionstamp¹ is a value composed of the database's globally ordered commit version and a user-controlled part. It's assigned at commit time, thus it reflects the exact order of successful commits across the system.

  ┌─────────────────────────────────────────────────────┬──────────────┐
  │              Database commit version                │  User bytes  │
  │                    (10 bytes)                       │   (2 bytes)  │
  ├─────────────────────────────────────────────────────┼──────────────┤
  │  Assigned by DB at commit time. Monotonically       │  Set by the  │
  │  increasing across all transactions.                │  application │
  └─────────────────────────────────────────────────────┴──────────────┘
                          12 bytes total

The database portion guarantees global ordering across transactions. The user bytes allow ordering multiple writes within the same transaction. This enables batch inserts with defined order.

Versionstamps act as both a replacement for auto-incrementing primary keys, and a global ordering primitive.

How this differs from Postgres

In Postgres, SERIALs or auto-incrementing primary keys are locally ordered. The number only indicates the order within the table. Additionally, the nextval() function is called per-insert, not at commit time. If two transactions are active concurrently, rows inserted in a transaction that commits later may have a lower value than rows inserted in a transaction that commits earlier. Rolled-back transactions also cause gaps in the sequence ².

The global ordering primitive in Postgres is the Log Sequence Number (LSN). It represents a position in the write-ahead log (WAL). The catch is that this value is internal to the WAL. There's no way to "use" the value on the application side, at least not without integrating with logical replication.

What does "using" the global order mean?

FoundationDB allows the user to do two things with versionstamps:

1. Embed the versionstamp in the value of a record (roughly equivalent to setting a column in Postgres).

   This allows for a number of interesting use cases on the application side, such as implementing optimistic concurrency control. Imagine two clients in a web app editing the same record concurrently. With versionstamps, it's trivial to detect a conflict and let the user know a conflict occurred. Because the ordering is global, you can also reason about ordering across different records.

2. Embed the versionstamp in the key of a record (roughly equivalent to setting a primary key in Postgres).

   This can be used for ordering. Since FoundationDB is a key-value store, in our mental model, we can think of the entire database as a huge ordered map. When reading from the database, you always query a range in the map. As a result, simply by deciding to make a "table" append-only we can immediately use it for change data capture.

{
  // Versionstamp as key
  ("events", 0x0000000abc120000 0000): { type: "user_created", id: 1 },
  ("events", 0x0000000abc120000 0001): { type: "user_created", id: 2 },
  ("events", 0x0000000abc150000 0000): { type: "order_placed", id: 1 },
  ("events", 0x0000000abc170000 0000): { type: "user_updated", id: 1 },

  // Versionstamp as value
  ("users", 1): { name: "Alice", version: 0x0000000abc170000 0000 },
  ("users", 2): { name: "Bob",   version: 0x0000000abc120000 0001 },
}                                      /* └─── 10 bytes ───┘ └ 2 ┘ */

Who benefits from versionstamps?

Anyone building something with change feeds:

• Event sourcing (or anything to do with audit logs)
• Distributed queues
• Replication
• Local-first frameworks

I've already discussed the optimistic concurrency control use case above. This could also be extended for frontend clients to get incremental updates efficiently. Just retrieve all records with versionstamp > last_versionstamp. These two pieces form the basis of many local-first frameworks that have emerged in the last few years.

Why aren't versionstamps everywhere?

FoundationDB operates on a different abstraction level than most database systems. Conceptually, it's on a lower level than SQL databases. In fact, the Record Layer³ is a relational layer built on top of FoundationDB. For this reason, it makes sense that the versionstamp primitive is exposed to the user. In a database like Postgres, MVCC is an internal mechanism hidden from the user.

It's not that other databases lack commit timestamps. As we saw, Postgres has LSNs, CockroachDB has hybrid logical clocks, TiDB has the TimeStamp Oracle. But none of these have the exact properties that versionstamps do.

• LSNs are internal to the WAL and not exposed to the user.
• CockroachDB's HLC do not guarantee global ordering for disjoint transactions.
• TiDB's TimeStamps are assigned before the transaction is committed, not after.

I imagine changing the semantics of properties that are fundamental to the functionality of the database would be next to impossible.

Outbox pattern is unnecessary with versionstamps

Without versionstamps, features built on change feeds are more complex since they require the use of the outbox pattern. Having an additional write within the same transaction is not necessarily a problem, but actually processing the outbox adds moving parts to the system. A separate worker is needed to poll the outbox, publish events, mark them as processed, and periodically clean up old entries. And even then, there are some caveats to consider⁴.

Contrast that to a system with versionstamps. The only polling needed is the same versionstamp > last_versionstamp we saw before. Any consumer just needs to store its high-water mark, and read from there.

As a matter of fact, FoundationDB doesn't even have a concept of CDC or replication. You can implement it all in the application layer, because versionstamps are a good abstraction.

Postscript

Fragno's data layer is in part inspired by FoundationDB. We only support non-interactive transactions and detect conflicts using optimistic concurrency control. We do not require global ordering, so we can get away with a hidden _version column per row. We have a built-in outbox pattern, Durable Hooks, that does the heavy lifting.
